135

Keysight X-Series Signal Generators

N5171B/72B/73B EXG and N5181B/82B/83B MXG

User’s Guide

6 Using Pulse Modulation for All Models

with Options UNU, UNW, 320

Before using the information in this chapter, you should be familiar with the basic operation of the

signal generator. If you are not comfortable with functions such as setting the power level and

frequency, refer to Chapter 4, “Front Panel Operation for All Models”, on page 55 and familiarize

yourself with the information in that chapter.

— Pulse Characteristics on page 137

— The Basic Procedure on page 139

— Example on page 140

— Pulse Train (Option 320 – Requires: Option UNW) on page 141
