Keysight X-Series Signal Generators

N5171B/72B/73B EXG and N5181B/82B/83B MXG

User’s Guide

4 Front Panel Operation for All Models

This chapter describes front panel operation for Keysight N5171B/72B/73B EXG and

N5181B/82B/83B MXG X-Series signal generators.

— Returning to a Known State with the Preset Key on page 56

— Viewing Key Descriptions with the Help Key on page 56

— Entering/Editing Numbers and Text with Number and Arrow Keys on page 57

— Setting Frequency and Amplitude with FREQ and AMPTD Keys on page 59

— Setting ALC Bandwidth Control with Amplitude Softkeys on page 61

— Using Swept Signal Mode (Configuring a Swept Output) on page 62

— Using Analog Modulation on the RF Carrier Signal (Option UNT) on page 70

— Working with Files (Viewing/Storing/Loading/Moving) on page 72

— Reading Error Messages on page 84

For information on remote operation, refer to the Programming Guide.
