147

Keysight X-Series Signal Generators

N5171B/72B/73B EXG and N5181B/82B/83B MXG

User’s Guide

7 Basic Digital Operation for N5172B/82B—

No BBG Option Installed

Before using the information in this chapter, you should be familiar with the basic operation of the

signal generator. If you are not comfortable with functions such as setting the power level and

frequency, refer to Chapter 4, “Front Panel Operation for All Models”, on page 55 and familiarize

yourself with the information in that chapter.

See also “Adding Real-Time Noise (AWGN) to a Dual ARB Waveform” on page 324.
