Keysight EXG and MXG X-Series Signal Generators User’s Guide 387

Using Avionics VOR/ILS Softkeys for N5171B/72B and N5181B/82B with Option 302

Using ILS Glide Slope Softkeys

To set or return the ILS Glide Slope parameters to a default state

1. Press Aux Fctn > Avionics > ILS Glide Slope

2. Press More 1 of 2

3. Press Recall Default Settings

These softkeys return the ILS Glide Slope parameters

to a set of default state conditions.

ILS Glide Slope Menu Parameters Default State

ILS GS Mode OFF

Carrier Freq Index 1 334.70 MHz

Up/Down menu Up Frequency 90 Hz

Down Frequency 150 Hz

Up/Down Phase 0.00 deg

DDM/SDM menu Fly Up/Down Up

DDM 0.0000

DDM uA 0.0 uA

DDM% 0.00%

SDM 80.0%

COM/ID menu

a. For information on the COM/ID menu,

refer to

“Using COM/ID Softkeys” on page 354.
