Keysight EXG and MXG X-Series Signal Generators User’s Guide 139
Using Pulse Modulation for All Models with Options UNU, UNW, 320
The Basic Procedure
The Basic Procedure
1. Preset the signal generator.
2. Set the carrier (RF) frequency.
3. Set the RF amplitude.
4. Configure the modulation:
a. Set the pulse source: Press Pulse > Pulse Source > selection
b. Set the parameters for the selected pulse source:
5. Turn on the modulation: Pulse Off On softkey to On.
The the PULSE annunciator lights, indicating that you enabled modulation.
6. Output the modulated signal from the signal generator: Press the front panel RF On Off key.
The RF output LED lights, indicating that the signal is transmitting from the RF output connector.
See also, “Using Analog Modulation on the RF Carrier Signal (Option UNT)” on page 70.
Square Free Run
(default)
Triggered Adjustable Doublet Trigger Doublet Gated Pulse
Train
a
a. Requires Option 320.
External
Pulse
Rate
⎯⎯ ⎯ ⎯ ⎯ ⎯⎯
⎯ Pulse
Period
⎯⎯ ⎯Pulse
Period
⎯⎯
⎯ Pulse
Delay
Pulse
Delay
Pulse Delay Pulse Delay ⎯ Pulse
Delay
⎯
⎯ Pulse
Width
Pulse
Width
Pulse Width Pulse Width Pulse
Width
⎯⎯
⎯⎯ ⎯Pulse 2 Delay ⎯⎯⎯⎯
⎯⎯ ⎯Pulse 2 Width ⎯⎯⎯⎯
⎯⎯ ⎯ ⎯ ⎯ ⎯
Pulse On
b
b. Up to 2047 pulse cycles (elements) composed of both Pulse On and Pulse Off can be user
defined.
⎯
⎯⎯ ⎯ ⎯ ⎯ ⎯
Pulse Off
b
⎯
