346 Keysight EXG and MXG X-Series Signal Generators User’s Guide
Using Avionics VOR/ILS Softkeys for N5171B/72B and N5181B/82B with Option 302
Using VOR [VHF Omnidirectional Range] Softkeys
Because VOR carrier frequencies and ILS Localizer carrier frequencies have a
frequency range that overlaps, only frequencies where the 100 kHz digit is even
(tenths of a megacycle count is even) are used as VOR carrier frequencies.
The default VOR carrier frequency Index is 1 and corresponds to 108.00 MHz.
VOR Carrier Frequencies (MHz) Carrier Freq Index = 1 to 160
1 to 32 33 to 64 65 to 96 97 to 128 129 to 160
108.00
111.20 113.20 114.80 116.40
108.05 111.25 113.25 114.85 116.45
108.20 111.40 113.30 114.90 116.50
108.25 111.45 113.35 114.95 116.55
108.40 111.60 113.40 115.00 116.60
108.45 111.65 113.45 115.05 116.65
108.60 111.80 113.50 115.10 116.70
108.65 111.85 113.55 115.15 116.75
108.80 112.00 113.60 115.20 116.80
108.85 112.05 113.65 115.25 116.85
109.00 112.10 113.70 115.30 116.90
109.05 112.15 113.75 115.35 116.95
109.20 112.20 113.80 115.40 117.00
109.25 112.25 113.85 115.45 117.05
109.40 112.30 113.90 115.50 117.10
109.45 112.35 113.95 115.55 117.15
109.60 112.40 114.00 115.60 117.20
109.65 112.45 114.05 115.65 117.25
109.80 112.50 114.10 115.70 117.30
109.85 112.55 114.15 115.75 117.35
110.00 112.60 114.20 115.80 117.40
110.05 112.65 114.25 115.85 117.45
110.20 112.70 114.30 115.90 117.50
110.25 112.75 114.35 115.95 117.55
110.40 112.80 114.40 116.00 117.60
110.45 112.85 114.45 116.05 117.65
