64 Keysight Agile Signal Generator Service Guide
Replaceable Parts
Table 2-2 Cables
Reference
Designator
Description Part Number Figure
Number
W1 Cable Assembly - Coaxial A31/A40 50-Ohm MCX-Male Bulkhead Front
Mounted BNC-Female 975 mm-LG, Color clip "Brown/Orange" to "EXT2"
8121-2587 2-1
2-22
2-23
W2 Cable Assembly - Coaxial A31/A40 50-Ohm MCX-Male Bulkhead Front
Mounted BNC-Female 975 mm-LG, Color clip "Brown/Yellow" to "EXT1"
8121-2587 2-1
2-22
2-23
W3 Cable Assembly - Coaxial A31/A40 50-Ohm MCX-Male Bulkhead Front
Mounted BNC-Female 675 mm-LG, Color clip "Brown/Green" to "Gate Pulse
Trigger"
8121-2589 2-1
2-22
2-23
W4 Cable Assembly - Coaxial A31/A40 50-Ohm MCX-Male Bulkhead Front
Mounted BNC-Female 675 mm-LG, Color clip "Brown/Blue" to "Sync Out"
8121-2589 2-1
2-22
2-23
W5 Cable Assembly - Coaxial A31/A40 50-Ohm MCX-Male Bulkhead Front
Mounted BNC-Female 675 mm-LG, Color clip "Brown/White" to "Video Out"
8121-2589 2-1
2-22
2-23
W6 Cable Assembly - Coaxial A31/A40 50-Ohm MCX-Male Bulkhead Front
Mounted BNC-Female 320 mm-LG, Color clip "Brown/Red" to "LF OUT"
8121-2593 2-1
2-22
2-23
W7 Cable Assembly - RF, Semi-Rigid, DAC Board Output to Agile Cleanup Input N5191-20117 2-13
W8 Cable Assembly - RF, Semi-Rigid, 6 GHz Rear Panel Input to DAC 6 GHz
Input
N5191-20118 2-13
W9 Cable Assembly - RF, Semi-Rigid, 6 GHz Rear Panel Jumper N5191-20119 2-3
W10 Cable Assembly - RF, Semi-Rigid, Agile Cleanup Bypass Output N5191-20122 2-14
2-15
2-16
2-17
W11 Cable Assembly - RF, Semi-Rigid, Agile Cleanup Output to Multiplier Input N5191-20123 2-14
2-15
2-16
2-17
W12 Cable Assembly - RF, Semi-Rigid, Low Band Output to Mod Filter Low Band
Input
NOTE: for instruments with serial prefix < MY/SG/US5619xxxx, cables W12
and W15 MUST be replaced at the same time.
N5191-20238 2-14
2-15
2-16
2-17
W13 Cable Assembly - RF, Semi-Rigid, Multiplier Low Band Output to Mod Filter
Low Band Input
N5191-20125 2-14
2-15
2-16
2-17
