ARB:TERM:LAST OFF,(@1)
The parameter setting remains at the last Arb value after the Arb completes.
ARB:TERM:LAST ON,(@1)
Create a user-defined current or voltage Arb from the present Arb property values:
ARB:CURR:CONV (@1)
ARB:VOLT:CONV (@1)
Specify the number of time the arb repeats, or repeat the Arb continuously (INF):
ARB:COUN 10,(@1)
ARB:COUN INF,(@1)
Constant-Dwell Parameters
Parameter Description
Dwell per Step The dwell time for each step in seconds. Values range from10.24 μs to 0.30 s.
Import (.csv format) Imports a current or voltage CD Arb list.
Export (.csv format) Exports a current or voltage CD Arb list.
Min The minimum value of the imported Arb.
Max The maximum value of the imported Arb.
Avg The average value of the imported Arb.
Points The number of points in the imported Arb.
Time The total time of the imported Arb.
Repeat Count The maximum repeat count for CD Arbs is 256.
From the remote interface:
The dwell time for each step in seconds.:
ARB:CURR:CDW:DWEL 0.01,(@1)
ARB:VOLT:CDW:DWEL 0.01,(@1)
3 Using the Source Functions
110 Keysight N6705C Operating and Service Guide
