Preliminary Information
Check for Items Supplied
Inspect the Unit
Review Safety Information
Observe Environmental Conditions
Check for Items Supplied
Before getting started, check the following list and verify that you have received these items with your
unit. If anything is missing, please contact your nearest Keysight Sales and Support Office.
Mainframe Items Description Part Number
Power Cord A power cord suitable for your location. Call Keysight Sales & Support Office
Digital Connector plug 8-pin connector for connecting signal lines to the digital port. Keysight 1253-6408
Phoenix Contact MC 1,5/8-ST-3,5
AUX Measurement
Connector plug (2)
8-pin connector plug for the auxiliary measurement inputs.
Only used with Models N6781A and N6785A.
Keysight 1253-6408
Phoenix Contact MC 1,5/8-ST-3,5
Spare grommets Two spare grommets for rear panel sense and load wiring. Keysight 0400-1009
Automation-Ready CD Contains Keysight IO Libraries Suite. Keysight E2094N
Quick Start Tutorial A tutorial to help you quickly getstarted. Keysight N6705-90005
T-10 Torx tool Tool for installing or removing power modules. Keysight 8710-2416
DC Power Module Items Description Part Number
8 A Output Connector plug One 8 A, 8-pin connector plug for connecting power and sense
leads. Only used in Models N678xA SMU.
Keysight 1253-6408
Phoenix Contact MC 1,5/8-ST-3,5
12 A Output Connector plug One 12 A, 4-pin connector plug for connecting power and
sense leads. Used in all except N6731B, N6741B, N6753A-
N6756A, N6763A-N6766A, N6773A, N678xA SMU.
Keysight 1253-5826
Phoenix Contact MSTB 2,5/4-STF
20 A Output Connector plug One 20 A, 4-pin connector plug for connecting power and
sense leads. Only used in N6731B, N6741B, N6754A, N6756A,
N6764A, N6766A, N6773A.
Keysight 1253-6211
Phoenix Contact PC 4/4-ST-7,62
50 A Output Connector plug One 50 A, 2-pin connector plug for connecting power leads.
Only used in N6753A, N6755A, N6763A, N6765A.
Keysight 1253-7187
Molex 39422-0002
AUX Measurement connector
plug
A 2-pin connector plug for connecting the auxiliary meas-
urement inputs. Only used in N6781A and N6785A.
Keysight 1253-8485
Phoenix Contact FMC 1,5/2-ST-3,5
Small Sense Jumpers Two small jumpers for local sensing at the output connector.
Used in all except N6731B, N6741B, N6753A-N6756A,
N6763A-N6766A, N6773A, N678xA SMU.
Keysight 8120-8821
Phoenix Contact EPB 2-5(1733169)
2 Installation
48 Keysight N6705C Operating and Service Guide
