Test Equipment and Setups
Equipment Required
Measurement Setups
Equipment Required
The test equipment recommended for the verification and calibration procedures is listed below. If the
exact instrument is not available, substitute calibration standards of equivalent accuracy.
Instrument Requirements Recommended Model Use
1
Digital Multimeter Resolution: 10 nV @ 1V
Readout: 8 1/2 digits
Accuracy: 20 ppm
Keysight 3458A or equivalent V, C
Current Shunt
2
15 A (0.1Ω )
30 A (0.1Ω )
50 A (0.05Ω )
Guildline 9230A-15R
Guildline 9230A-30
Guildline 9230A-50
V, C
Load Resistors 25 Ω , 250 W, 1% (N6751A/52A/61A/62A)
4 Ω, 250 W, 1% (N6751A/52A/61A/62A)
20 kΩ, 1%, 1/8W(for option 1UA/2UA)
10 Ω , 1%, 1/8W (N678xA SMU)
10 kΩ, 1%, 1/8W(N678xA SMU)
1 MΩ , 1%, 1/8W (N678xA SMU)
Vishay NH-250-25Ω -1%
Vishay NH-250-4Ω -1%
C
C
V, C
V, C
V, C
V, C
Electronic load
2
150 V, 50 A minimum, with transient capability and a slew
rateof 833 kA/s or better
Keysight N3300A mainframe, with
N330xA modules
V, C
Keysight N6784A Load for N678xA SMU and N6783A (setto CC load mode) Keysight N6784A V
GPIB controller Full GPIB capabilities Keysight 82350B or equivalent V, C
Oscilloscope Sensitivity: 1 mV
Bandwidth Limit: 20 MHz
Probe: 1:1 with RFtip
Keysight DSO6054A or equivalent V
RMS Voltmeter True RMS
Bandwidth: 20 MHz
Sensitivity: 100 µV
Rhode and SchwartzModel URE3
or equivalent
V
Differential Amplifier Bandwidth: 20 MHz LeCroy DA1855A, DA1850A, or
equivalent
V
Terminations 1 – 50Ω BNC termination
2 – 50Ω 1/8 Wtermination resistors
V
Variable voltage transformer
or AC source
Adjustable to highest rated input voltage
Power: 500 VA
Keysight 6813B or equivalent V
RC – for N678xA transient
test
Capacitor: 150 μF fixed film
Resistor 50 mΩ
EPCOS B32526R0157K
Vishay LVR01R0500FE70
V
1
V = Verification C = Calibration
2
Dependent on rating of model being tested
