[SOURce:]ARB:SEQuence:STEP:CURRent:SINusoid:FREQuency<value>, <step#>, (@<chanlist>)
[SOURce:]ARB:SEQuence:STEP:CURRent:SINusoid:FREQuency? [MIN|MAX,] <step#>, (@<chanlist>)
[SOURce:]ARB:SEQuence:STEP:VOLTage:SINusoid:FREQuency <value>, <step#>, (@<chanlist>)
[SOURce:]ARB:SEQuence:STEP:VOLTage:SINusoid:FREQuency? [MIN|MAX,] <step#>, (@<chanlist>)
Specifies the frequency of the current or voltage sine wave in Hertz for Arb sequence steps.
Parameter Typical Return
3.8147E-5 - 1.0E4 | MIN | MAX, *RST 1 <frequency>
Step 0 - 99, *RST 0 (none)
Programs a current frequency: ARB:CURR:SIN:FREQ 10,(@1)
Programs a voltage frequency: ARB:VOLT:SIN:FREQ 10,(@1)
Programs a current frequency for step 0: ARB:SEQ:STEP:CURR:SIN:FREQ 10, 0,(@1)
[SOURce:]ARB:CURRent:SINusoid:OFFSet<value>, (@<chanlist>)
[SOURce:]ARB:CURRent:SINusoid:OFFSet? [MIN|MAX,] (@<chanlist>)
[SOURce:]ARB:VOLTage:SINusoid:OFFSet <value>, (@<chanlist>)
[SOURce:]ARB:VOLTage:SINusoid:OFFSet? [MIN|MAX,] (@<chanlist>)
Specifies the offset of the current or voltage sine wave from zero. Referenced to I1 and V1 in the
Sinusoid diagrams.
[SOURce:]ARB:SEQuence:STEP:CURRent:SINusoid:OFFSet<value>, <step#>, (@<chanlist>)
[SOURce:]ARB:SEQuence:STEP:CURRent:SINusoid:OFFSet? [MIN|MAX,] <step#>, (@<chanlist>)
[SOURce:]ARB:SEQuence:STEP:VOLTage:SINusoid:OFFSet <value>, <step#>, (@<chanlist>)
[SOURce:]ARB:SEQuence:STEP:VOLTage:SINusoid:OFFSet? [MIN|MAX,] <step#>, (@<chanlist>)
Specifies the offset of the current or voltage sine wave from zero for Arb sequence steps.
Except for models N678xA SMU, the output cannot generate negative amplitudes.
Therefore, the offset value cannot be less than the peak value of the sine wave.
Parameter Typical Return
Current: 0 - maximum|MIN|MAX, *RST 0
Voltage: 0 - maximum|MIN|MAX, *RST 0
The maximum value varies, depending on the current or voltage
rating of the power module.
<offsetvalue>
Step 0 - 99, *RST 0 (none)
Programs a current offset: ARB:CURR:SIN:OFFS 2,(@1)
Programs a voltage offset: ARB:VOLT:SIN:OFFS 5,(@1)
Programs a current offsetfor step 0: ARB:SEQ:STEP:CURR:SIN:OFFS 2, 0,(@1)
