Parameter Typical Return
DWELl | TRIGgered, *RST DWELl DWEL or TRIG
Step 0 - 99, *RST 0 (none)
Specify trigger pacing for sequence step 1: ARB:SEQ:STEP:PAC TRIG, 1, (@1)
l If the <step#> specified is an existing sequence step, that step will be changed to the specified
waveshape with all parameters reset to default values.
l New sequence steps must be specified sequentially. To create a new sequence step, <step#>
should be specified to be the current length of the sequence (see
[SOURce:]ARB:SEQuence:LENgth?). When a step is added, all parameters of the step waveform
are reset to their default values.
[SOURce:]ARB:SEQuence:TERMinate:LAST <Bool>, (@<chanlist>)
[SOURce:]ARB:SEQuence:TERMinate:LAST? (@<chanlist>)
Determines the output value when the Arb sequence terminates. The state is either ON (1) or OFF (0).
When
ON
The output voltage or current remains atthe last Arb sequencevalue. The last voltage or current Arb value becomes the IMMediate
value when the sequence completes.
When
OFF
The output returns to the settings that were in effect before the sequence started. This also applies when the sequence is aborted,
Parameter Typical Return
0|OFF|1|ON, *RST Off 0or1
Sets the sequence to terminatewith the voltage or current setatthe last sequence value:
ARB:SEQ:TERM:LAST ON,(@1)
l The query returns 0 if the output returns to the settings that were in effect before the sequence
started, and 1 if the output voltage or current remains at the last sequence value.
7 SCPI Programming Reference
266 Keysight N6705C Operating and Service Guide
