SA (Spectrum Analyzer) Mode (Option 233–Mixed Analyzers)
SA Mode Settings
Figure 9-4 AM DSB (Metrics) – Demodulation Spectrum
In the graphic above, Analog Demod ON and Demod Metrics is indicated
above in the x2 displays of carrier spectrum content. For this example, AM
Modulation Metrics are displayed in the lower half of the display. See also,
Figure 9-5 on page 175, Figure 9-6 on page 176, Figure 9-7 on page 176, and
Figure 9-8 on page 177.
This section contains the following:
“How to select Analog Demod (Metrics)” on page 169
“How to make Analog Demodulation (Metrics)
Settings” on page 170
“Setting the Alternate Frequency (AF) Freq/Dist
Softkeys” on page 171
“Setting the Alternate Frequency (AF) RBW Softkey”
on page 171
“Setting the Audio Capture Playback Softkeys” on
page 172
“How to Set the Demod Filters” on page 173
“Setting the Marker Counter Gate Softkey” on
page 175
Keysight N9938-90003 User's Guide
