SA (Spectrum Analyzer) Mode (Option 233–Mixed Analyzers)
SA Mode Settings
— Save Antenna/Cable Save the modified Antenna/Cable to a file on the
specified Storage Device.
— Recall Antenna/Cable
Read an existing Antenna/Cable file from the
specified Storage Device.
— Storage Device
Choose from: Internal, USB, SD. Learn more about these
selections in “Set File Type and Select Device” on page 727.
When finished, press Back
to return to the previous menu.
Using the Antenna/Cable Editor
The Antenna Editor and the Cable Editor menus are very similar. Both tables
include header information, and a Frequency/Value table.
Figure 9-2 FieldFox Antenna Editor– E–Field and H-Field Units Displayed
How to use the Antenna/Cable Editor
—Press Scale/Amptd > More > Corrections then choose:
— Antenna Off
to open the antenna editing softkeys
— Cable Off
to open the cable editing softkeys
Once you have selected Antenna or Cable to edit:
—Press New
then Yes to clear all data from the existing Antenna or Cable
table and reset header information to default settings.
—Then Edit Antenna
or Edit Cable to open the Antenna / Cable Editor.
E-Field Units
H-Field Units
Keysight N9938-90003 User's Guide
