40 Keysight N9927-90020 User’s Guide
Preparing for Initial Use of Your New FieldFox
Take the FieldFox Tour
Left Side Panel
Connector Description Learn More:
Audio output jack for use with SA Mode Tune and Listen. “Tune & Listen
(AM/FM)” on page 163
DC Voltage Source for use with external DC Bias. “Variable Voltage
Source (Opt. 309)” on
page 708
DC power connector used to connect to the AC/DC adapter. Maximum: 19
VDC, 4 ADC.
“Internal Charging with
the AC/DC Adapter ” on
page 739
