System Settings
System Configuration
— 3.3V 5V – Settable to: 3.5 VDC or 5 VDC. When the bias voltage is
set to ON and when the GPS is set to Internal. This system was
designed for an active antenna such as the Keysight N9910X-825
Saving Data with GPS Enabled
GPS position and clock data are included when data is saved with the following
files types: *.csv, *.SnP, State, State+Trace data save.
A warning is shown if the GPS is ON but unlocked at time of save, or if the GPS
feature is ON but no GPS is physically present at time of save.
The following is a sample S1P file with GPS information:
!GPS Latitude: 38 28.87717 N
!GPS Longitude: 122 42.66625 W
!GPS TimeStamp: 06/25/2010 16:24:48
!GPS Seconds Since Last Read: 2s
Saving GPS Display Data
To save the current GPS data displayed:
—Press Save/Recall 9
—Then Save File Picture (PNG)
— A menu opens to enable naming the file you are saving (*.png).
Keysight N9938-90003 User's Guide
