System Settings
System Configuration
How to configure LAN settings
The first three ‘Current...’ settings can NOT be edited.
— Press System 7.
— Then System Configuration.
—Then More.
— Then LAN.
— Use the arrows to select one of the following, then press Edit.
— Hostname Change the name that can be used to address the FieldFox if
your server supports this feature. The default hostname is generated
automatically.
— Obtain IP Choose from:
— DHCP - IP Address is assigned dynamically. If your server supports
this feature, the IP Address for the FieldFox is assigned each time it is
started.
Table 29-1 LAN LEDs (N995xA, N996xA
, and applies to: N991xA/2xA/3xA units with serial
number prefixes ≥5607)
LAN LEDs (N995xA, N996xA, and applies to: N991xA/2xA/3xA units with serial number
prefixes ≥5607) )
When FieldFox is connected to the LAN, the flashing LAN LEDs have the following
definitions:
Green: Flashing indicates packets are being transferred.
Yellow:
— Flash, pause = 10 Mbit link speed
— Flash, flash, pause = 100 Mbit link speed
— Flash, flash, flash, pause = 1 GBit link speed
Keysight N9938-90003 User's Guide
