SA (Spectrum Analyzer) Mode (Option 233–Mixed Analyzers)
SA Mode Settings
All three or a subset of the individual alignments are required for each specific
mode, depending on the type of measurement supported by it:
SA:
— InstAlign Amplitude Alignment
— RF Burst Amplitude Alignment
RTSA:
— InstAlign Amplitude Alignment
— RF Burst Amplitude Alignment
— Channel Equalization
Channel Scanner:
— InstAlign Amplitude Alignment
EMI Measurements:
— InstAlign Amplitude Alignment
— WidePath Burst Trigger Alignment
— Channel Equalization
ERTA:
— InstAlign Amplitude Alignment
IQA:
— InstAlign Amplitude Alignment
— RF Burst Amplitude Alignment
— Channel Equalization
Built-in Power meter
— InstAlign Amplitude Alignment
Default settings and recommended use model for many applications:
— Coupled individual alignments
—Coupled state is Auto
— Individual alignments are not accessible via front panel soft-keys
— Individual alignments cannot be UnCoupled
For special cases, the individual alignments can be accessible via the front
panel soft-keys using the Preference setting SA - Individual Alignment
Control
> On/Off. This enables a soft-key for access to Individual Alignments
when this preference is set to ON: Cal 5
> Individual Align. For more refer to
“Preferences” on page 686, in Chapter 29 System Settings.
