SA (Spectrum Analyzer) Mode (Option 233–Mixed Analyzers)
SA Mode Settings
— Cable Off – Opens a softkey menu to enable/disable a cable and edit,
save, create a new cable description table, recall, and set a storage
device location.
— More
– Opens a softkey menu to View Corrections and set the
Amplitude Correction type for your antenna.
Learn more, see “Selecting and Viewing Corrections” on page 159.
— SrcSide Antenna Off / On
Edit/Recall an Antenna file to be used to
transmit.
— RcvrSide Antenna Off / On
Edit/Recall an Antenna file to be used to
receive.
— SrcSide Cable Off / On
Edit/Recall a Cable file to be used on the
Source side.
— RcvrSide Cable Off / On
Edit/Recall a Cable file to be used on the
Receiver side.
Selecting and Viewing Corrections
—Press Scale/Amptd > More > Corrections > More
— View Corrections ON OFF Turn ON and OFF Pink Trace - Antenna/Cable
corrections. This is a composite of all cable/antenna corrections that are
currently applied. Available as a useful visual aid, the zero “dB” level (no net
correction) is mapped to appear at the -50 dBm on-screen level.
— Amp Corr Select [Triaxial XYZ]
- then choose one of the following:
— Default
Receiver side only antenna measurements.
— Src/Rcvr Split
to work with non-triaxial receiver and source side
antenna measurements.
— Triaxial XYZ
(default, when Channel Power is on and when a
compatible triaxial antenna’s factors have been imported) for
measuring channel measurements and EMF.
How to Use the Antenna Softkeys
The following menu appears when any of the above Antenna or Cable softkeys
are pressed:
— Antenna/Cable ON OFF
Turn correction ON or OFF for this Antenna/Cable.
— Edit Antenna/Cable
Edit an Antenna/Cable Correction table. See Using the
Antenna/Cable Editor (below) for more information.
— New
Create a new Antenna/Cable. See Using the Antenna/Cable Editor
(below) for more information.
Keysight N9938-90003 User's Guide
To Next Page
