System Settings
Display
—Then Preferences
—Then Preferences
— Then scroll to Global Settings > Battery Saver
— ON – To conserve battery power, the RF source power is turned OFF
at the end of each CAT, NA, and VVM mode sweep. This behavior
does not impact FieldFox measurements.
— OFF – Source power is kept ON at all times, including during trigger
Hold mode and between single sweep acquisitions. The RF source
stays at the stop frequency until another sweep begins. This provides
a constant, uninterrupted RF output from the RF OUT port. This
behavior also provides the highest trace stability sweep-to-sweep
which may only be evident while using either single sweep or
Run/Hold. With Battery Saver OFF, the use of a full battery charge is
reduced by approximately 45 minutes.
Startup Mode
The Startup Mode setting determines the mode that becomes active (visible)
when User Preset is set to OFF (Factory Preset) and the FieldFox is powered
ON. See “User Preset” on page 673.
How to setup Startup Mode
—Press System 7
—Then Preferences
—Then Preferences
— Then scroll to Global Settings > Startup Mode and press Edit.
— Then repeatedly press the Startup Mode
to scroll through the available
choices.
— <Default>
is the factory default mode for your FieldFox model.
— Built-in Power Meter Mode is NOT allowed as a Startup Mode.
Display
Choose the Display values (Display Colors, Trace Width, Brightness, Title
Enabled, Title). See “Display (Settings)” on page 675.
How to select Display values:
—Press System 7
—Then Preferences
—Then Preferences
Keysight N9938-90003 User's Guide
