Keysight N9927-90001 User’s Guide 533
Channel Scanner (Option 312)
How to Set Up Channel Scanner
Step 3. Modify Scale and the Display Color Bar Settings
To assign colors to low and high power values:
1. Press Scale/Amptd
> Red Limit to set high power values and to set the
color.
2. Press Blue Limit
to set low power values and to set the color.
3. And, then press System
> Display > Display Colors, to set Indoor, Outdoor,
or other display colors. See also Chapter 26, “Channel Scanner (Option
312)”, on page 523.
Figure 26-11 Outdoor Display Colors
