3-2 Site Preparation
3 Structural Requirements
Floor Requirements
The i3070 testhead is the heaviest part of the system. The controller and test
development stations present no special load-bearing concern. The following table
lists the approximate weights of the systems.
i307x
Anti-Static Surface
Static electricity is destructive to your production process and to your board test
system. Careless handling and poor planning can cost you yield and system
reliability.
This is not an exhaustive description of anti-static precautions but a reminder as
you plan your system area:
• Anti-static flooring. Plan to use an anti-static floor covering or mats.
• Grounding straps. Plan for foot straps in conjunction with anti-static flooring
and wrist straps for system operators. The testhead has external connectors for
wrist straps.
• Anti-static DUT storage. Plan for anti-static tote bins for your
devices-under-test and storage for anti-static bags.
Table 3-1 System weights
System Type Product Weight
E9903G Testhead
523 kg (1153 lb)
Testhead on pallet
776 kg (1710 lb)
E9902G Testhead
425 kg (937 lb)
Testhead on pallet
678 kg (1495 lb)
E9905G Testhead
386 kg (851 lb)
Testhead on pallet
561 kg (1237 lb)
