3-4 Site Preparation
3 Structural Requirements
Dimensions of the Uncrated System
When removed from the crate, the testhead can be rolled on its casters.
Table 3-3 lists the dimensions of the uncrated testhead.
Equipment Rating
• Pollution degree 2
• Installation category II
• Altitude: Up to 2000 m
• Humidity: 5% to 80%
• Electrical supply: 208 Vac or 415 Vac, 50/60Hz, 30 A max, 3 phase
• Temperature: 0°C to 40°C
• Mains supply voltage fluctuations are not to exceed 10% of the nominal supply
voltage
This equipment is for indoor use only.
Table 3-3 Dimensions of the uncrated system
System Type Dimension Measurement
E9903G/E9902G Width 1490 mm
Depth 935 mm
Height 887 mm
E9903G/E9902G with side pod Width 1765 mm
Depth 935 mm
Height 887 mm
E9905G Width 954 mm
Depth 935 mm
Height 887 mm
E9905G with side pod Width 1229 mm
Depth 935 mm
Height 887 mm
