Structural Requirements 3
Site Preparation 3-3
Moving Access Requirements
The system is shipped from the factory on one large crate (on a pallet) and several
smaller crates or boxes. If the large testhead crate is too large to move to your
system’s destination, you will need to unpack the testhead and roll it on its casters.
Other smaller boxes, containing the controller and test development hardware,
should not present access problems.
This section contains:
• Dimensions of the Crated System
• Dimensions of the Uncrated System
• Access Requirements
Dimensions of the Crated System
Table 3-2 Dimensions of the crated system
System Type Dimension Measurement
E9903G/E9902G Width 2153 mm
Depth 1220 mm
Height 1400 mm
E9905G Width 1617 mm
Depth 1220 mm
Height 1400 mm
