Display Settings 9
Keysight InfiniiVision 3000T X-Series Oscilloscopes User's Guide 159
1 Press [Display] (or [Display] > More on 1 GHz and 1.5 GHz bandwidth models).
2 Press the Grid softkey; then, turn the Entry knob to select the grid type.
To adjust the grid intensity
To adjust the display grid (graticule) intensity:
1 Press [Display].
2 Press the Intensity softkey; then, turn the Entry knob to change the
intensity of the displayed grid.
The intensity level is shown in the Intensity softkey and is adjustable from 0 to
100%.
Each major vertical division in the grid corresponds to the vertical sensitivity
shown in the status line at the top of the display.
Each major horizontal division in the grid corresponds to the time/div shown in the
status line at the top of the display.
To freeze the display
To freeze the display without stopping running acquisitions, you must configure
the [Quick Action] key. See “Configuring the [Quick Action] Key" on page 357.
1 Once the [Quick Action] key has been configured, press it to freeze the display.
2 To un-freeze the display, press [Quick Action] again.
Manual cursors can be used on the frozen display.
Many activities, such as adjusting the trigger level, adjusting vertical or horizontal
settings, or saving data will un-freeze the display.
