Keysight DSOX3104T User Manual

354 Keysight InfiniiVision 3000T X-Series Oscilloscopes User's Guide
22 Utility Settings
For a 4-channel oscilloscope, connect BNC tees to the equal-length cables as
shown below. Then connect a BNC(f)-to-BNC(f) (barrel connector) to the tee as
shown below.
Figure 50 User Calibration cable for 2-channel oscilloscope
To Channel 1
To Channel 2
Long cable
to TRIG OUT
