Characteristics and Specifications 7
Supplemental Characteristics
E3632A User’s Guide 171
Supplemental Characteristics
Table 7 - 3 Supplemental characteristics
Output programming range
(maximum programmable values)
Low range 0 V to 15.45 V
0 V to 7.21 A
High range 0 V to 20.6 V
0 V to 1.545 A
OVP 1 V to 32 V
OCP 0 A to 7.5 A
Remote sensing capability Voltage drop Up to 1 V per each lead
Load regulation Add 5 mV to specification for each 1 V change in the output
lead due to load current changes.
Load voltage Subtract the voltage drop in the load leads from the specified
output voltage rating.
Temperature coefficient
[1]
(% of output offset)
Voltage 0.01% 3 mV
Current 0.02% 3 mA
Stability
[2]
(% of output offset)
Voltage 0.02% 1 mV
Current 0.1% 1 mA
Voltage programming speed
[3]
Up • 50 ms (full load)
• 20 ms (no load)
Down • 45 ms (full load)
• 400 ms (no load)
Output terminal isolation
(maximum, from chassis ground)
• 60 Vdc when connecting shorting conductors without
insulation between the () output and the () sense
terminals and between the (–) output and the (–) sense
terminals.
• 240 Vdc when connecting insulated shorting conductors
between the () output and the () sense terminals and
between the (–) output and the (–) sense terminals.
AC input ratings
(selectable via rear panel selector)
• 115 Vac 10%, 47 Hz to 63 Hz (standard)
• 230 Vac 10%. 47 Hz to 63 Hz (option 0E3)
• 100 Vac ±10%, 47 Hz to 63 Hz (option 0E9)
