Operation and Features 2
Storing and Recalling Operating States
E3632A User’s Guide 33
Storing and Recalling Operating States
You can store up to three different operating states in
non- volatile memory. This also enables you to recall the
entire instrument configuration with just a few key presses
from the front panel.
The memory locations are supplied with the reset states
from the factory for front- panel operation. Refer to the
description of
“*RST” on page 99 for more information. The
following steps show you how to store and recall an
operating state.
Front panel operation
Storing the operating state
1 Set up the power supply for the desired operating state.
The storage feature “remembers” output range selection,
the limit value settings of voltage and current, output
on/off state, OVP and OCP on/off state, and OVP and OCP
trip levels.
2 Turn on the storage mode.
Three memory locations (numbered 1, 2, and 3) are
available to store the operating states. The operating
states are stored in non- volatile memory and are
remembered when being recalled.
STORE 1
This message appears on the display for approximately
three seconds.
3 Select the storage location.
Turn the knob to the right to specify the memory
location 3.
STORE 3
To Next Page
