Operation and Features 2
Remote Interface Configuration
E3632A User’s Guide 55
4 Save the change and choose the parity.
NONE 8 BITS
The power supply is configured for 8 data bits with no
parity when shipped from the factory. Choose from one of
the following by turning the knob to the right or left:
None 8 Bits, Odd 7 Bits, or Even 7 Bits. When you set
parity, you are indirectly setting the number of the data
bits.
5 Save the change and turn off the I/O configuration mode.
CHANGE SAVED
The RS- 232 baud rate and parity selections are stored in
non- volatile memory, and does not change when power
has been off or after a remote interface reset. The power
supply displays a message to show that the change is now
in effect. If the baud rate and the parity are not changed,
NO CHANGE will be displayed for one second.
To exit the I/O configuration mode without any further changes, press
until the NO CHANGE message is displayed.
