22 2000/3000 X-Series Oscilloscopes Service Guide
2 Testing Performance
Conventions
The following conventions will be used when referring to oscilloscope models
throughout this chapter.
Blocking capacitor and shorting cap Note: if a BNC blocking capacitor is not available use an
SMA blocking capacitor.
Keysight 11742A +
Pomona 4288 +
Pomona 5088
Adapter (qty 3) N(m) to BNC(f) Keysight 1250-0780
50 Ohm Feedthrough Termination 50Ω BNC (f) to BNC (m) Keysight 0960-0301
Table 1 List of test equipment (continued)
Equipment Critical Specifications Recommended Model/
Part Number
* Required only for testing digital channels of oscilloscopes that have the MSO option.
Most parts and equipment are available at www.keysight.com. See respective manufacturer’s websites for their equipment.
†
These parts available at www.parts.keysight.com at the time this manual was published.
Table 2 Conventions
Models Referred to as:
MSO-X /DSO-X 2002A, MSO-X /DSO-X 2004A 70 MHz Models
MSO-X /DSO-X 2012A, MSO-X /DSO-X 2014A
MSO-X /DSO-X 3012A, MSO-X /DSO-X 3014A
100 MHz Models
MSO-X /DSO-X 2022A, MSO-X /DSO-X 2024A
MSO-X /DSO-X 3024A
200 MHz Models
MSO-X /DSO-X 3032A, MSO-X /DSO-X 3034A 350 MHz Models
MSO-X /DSO-X 3052A, MSO-X /DSO-X 3054A 500 MHz Models
MSO-X /DSO-X 3102A, MSO-X /DSO-X 3104A 1 GHz Models
