40 2000/3000 X-Series Oscilloscopes Service Guide
2 Testing Performance
To verify bandwidth (-3 dB)
This test checks the bandwidth (-3 dB) of the oscilloscope. In this test you will use
a signal generator and a power meter.
Table 13 Bandwidth (-3 dB) Test Limits
Models Test Limits
1 GHz Models All channels (-3 dB), dc to 1 GHz
500 MHz Models All channels (-3 dB), dc to 500 MHz
350 MHz Models All channels (-3 dB), dc to 350 MHz
200 MHz Models All channels (-3 dB), dc to 200 MHz
100 MHz Models All channels (-3 dB), dc to 100 MHz
70 MHz Models All channels (-3 dB), dc to 70 MHz
Table 14 Equipment Required to Verify Bandwidth (-3 dB)
Equipment Critical Specifications Recommended Model/Part
Signal Generator 100 kHz - 1 GHz at 200 mVrms Keysight N5181A
Power Meter 1 MHz - 1 GHz ±3% accuracy Keysight N1914A
Power Sensor 1 MHz - 1 GHz ±3% accuracy Keysight E9304A or N8482A
Power Splitter outputs differ by < 0.15 dB Keysight 11667A
Cable Type N (m) 24 inch Keysight 11500B
Adapter Type N (m) to BNC (m) Keysight 1250-0082 or
Pomona 3288 with Pomona
3533
50 Ohm Feedthrough
Termination
50
Ω BNC (f) to BNC (m), when
testing
2000 X-Series oscilloscopes
Keysight 0960-0301
