Testing Performance 2
2000/3000 X-Series Oscilloscopes Service Guide 51
Figure 9 Setting Up Equipment for 4-Channel External Trigger Sensitivity Test
Power Splitter
Power Sensor
Signal
Generator
Oscilloscope
Power
Meter
N Cable
N to BNC Adapter
50 Ohm Feedthrough
