RF Section Troubleshooting (N8973B, 74B, 75B Analyzers)
Troubleshooting
If any of the preselector control currents do not match the levels shown in
Table 4-8, the most probable causes are a misaligned YTF or the A15 Front End
Control Assembly. Perform the YTF characterization (press System,
Alignments, Advanced, Characterize Preselector) and re-check the control
current at various center frequencies.
Table 4-8 YTF Tune Current
Center Frequency
(GHz)
Control Current
(mA)
Tolerance
(mA)
5.0 106 ±20
10
a
215 ±25
15
a
324 ±30
20
a
430 ±40
26
a
560 ±50
a. N8975B/76B
Tolerances should be used as a guideline. The true test is whether or not
the analyzer will function and meet published specification.
