Keysight N9010B EXA Signal Analyzer Service Guide 419
Replaceable Parts
Hardware
Figure 14-15 Front End Parts - Millimeter Wave Instruments
Table 14-17
Item Description Keysight Part Number
1 A13 RF Front End Assembly N9020-60315
2 A13A1 Bandpass Filter 0955-2469
A13W1 Cable Assembly, A13J10 to A13A1 Input (semi-rigid) N9020-20229
A13W2 Cable Assembly, A13J10 to A13A1 Input (semi-rigid) N9020-20046
3 A12 YTF Preselector (not used in Opt 503) 5087-7383
4 J1 2.4 mm (m) Input Connector Assembly (Option 532, 544) N9030-60011
5 A11 Low Band Switch Assembly N9020-60051
W3 Cable Assembly, A11J2 to A13J2 (semi-rigid) N9020-20131
W4 Cable Assembly, A14J740 to A13J4 (semi-rigid) N9020-20156
W5 Cable Assembly, A16J702 to A13J1 (semi-rigid) N9020-20064
W7 Cable Assembly, A12 Output to A13J9 (semi-rigid) N9010-20006
