Fuses
Driver's side fuse panel
ICU Junction Block
Fuse Name Symbol Fuse Rating Circuit Protected
CHILD LOCK 15A Child Lock Relay, Child Unlock Relay
AFCU 10A AFCU
A/BAG IND 7.5A Overhead Console
MEMORY2 10A
Fuse - MEMORY2, Mood Lamp Unit, Crash Pad Mood Lamp LH/RH, ADP,
Head-Up Display, ADS Unit
To Next Page
