Fuses
Relay
Refer to the following table for the relay
type.
IG3 5 10A BMS (Battery Management System) Coolant 3Way Valve
VCU3 10A VCU
IG3 4 10A Electronic Water Pump #1, #2, Electronic A/C Compressor
IEB3 10A IEB Unit
IG3 6 10A Cooling Fan Motor, Front Electronic Oil Pump (4WD)
MDPS2 10A
MDPS Unit
* MDPS is the same as EPS (Electric Power Steering).
IG3 2 15A Front Inverter (4WD), VCU
Fuse Name Symbol Fuse Rating Circuit Protected
Relay Name Symbol TYPE
Charger Lock Relay MICRO
E-Shifter Relay MICRO
Rear Heated Relay MINI
ACC Relay MICRO
IG1 Relay MICRO
Blower Relay MICRO
IG2 Relay MICRO
Power Outlet Relay MICRO
Charger Unlock Relay MICRO
