Appendix B: Worksheets
192 P/N 3102351-EN • REV 005 • ISS 28DEC18
Worksheet B: Auxiliary/smoke power current load
Devices Qty
Standby
current (mA)
Alarm
current (mA)
Qty x Standby
current (mA)
Qty x Alarm
current (mA)
RPM 28 270
UM or MAB [1] 2 17
RLCD(F) 98 113
RLCD-C(F) 99 115
RLED-C(F) 28 62
GCI 36 146
LED24 6 34
RZI16-2 [2] 200 800
Sounder base [4] [4]
Total Aux Standby
current =
(cannot exceed
500mA)
[3]
x 1.25 =
(AUX to battery
standby current)
x 1.25 =
(AUX to battery
alarm current)
Totals (mA)
(transfer totals to Battery Calculation Worksheet)
[1] Enter 1 regardless of how many are installed. Only the first SIGA-UM or SIGA-MAB in the alarm state draws
current. The other ones do not because the system load sheds additional modules in alarm.
[2] If the panel AUX 1 is used to power an RZI16-2, the NAC alarm current must be reduced by the total AUX
alarm current amount over 500 mA.
[3] Total AUX alarm current =
1000 mA max for AUX 1*
1000 mA max for (AUX 1 + AUX 2)*
500 mA max for AUX 2
*You must reduce the total NAC alarm current by the total amount of AUX 1 + AUX 2 alarm current over
500 mA.
[4] See the sounder base installation sheet for currents
