Chapter 3: System operation
P/N 3102351-EN • REV 005 • ISS 28DEC18 157
When you disable an event:
• The common Disable LED turns on
• The common Trouble LED flashes and the panel goes into a trouble state
• The common Trouble relay changes state
• The disabled and active points indicators on the LCD increment
• The LCD displays a message indicating that the event is disabled.
Disabling and enabling loop events
Disabling a loop event prevents it from being displayed, printed, or reported off premises. This
is typically done during maintenance. For example, you might want to disable the Loop 1
unconfigured alarm event, if you are switching out a detector. Remember to enable the event
as soon as you have finished working.
When you disable a loop event:
• The common Disable LED turns on
• The common Trouble LED flashes and the panel goes into a trouble state
• The common Trouble relay changes state
• The disabled and active points indicators on the LCD increment.
• The LCD displays a message indicating which loop event is disabled.
Not all events can be disabled. Those that cannot are labeled as “forbidden.” The following
table lists events that can be disabled.
Table 45: Loop events that can be disabled
Event
ID
Loop 1 fault
001
Loop 2 fault
011
Loop 3 fault
021
Loop 4 fault
031
Loop 1 card fault
003
Loop 2 card fault
013
Loop 3
card fault 023
Loop 4 card fault
033
Loop 1 unconfigured alarm
004
Loop 2 unconfigured alarm
014
Loop 3 unconfigured alarm
024
