Panel configuration worksheet
The panel configuration worksheet is used to document the configuration and settings of the
system programming options.
Note: For default settings, see “Factory default settings” on page 42.
NAC
Class ☐ Class B ☐ Class A
Type
☐ Genesis + audible silence ☐ Continuous (silenceable) ☐ Temporal (nonsilence.)
☐ Genesis + audible/visible siln. ☐ Continuous (nonsilence.) ☐ Temporal (silenceable)
☐ Genesis (nonsilenceable) ☐ Coder - continuous ☐ Coder - temporal
☐ Coder - 120 SPM ☐ Coder - basic
Label Line 1
Label Line 2
Correlation grps.
Event notification
Trouble
Print ☐ Yes ☐ No
NET (1-8) ☐ Yes ☐ No
Dialer ☐ Acct 1 ☐ Acct 1 & 2 ☐ Acct 2 ☐ None
Code (four-digit coded output)
CID
Disable
Print ☐ Yes ☐ No
NET (1-8) ☐ Yes ☐ No
Dialer ☐ Acct 1 ☐ Acct 1 & 2 ☐ Acct 2 ☐ None
Code (four-digit coded output)
CID
Test
Print ☐ Yes ☐ No
NET (1-8) ☐ Yes ☐ No
Dialer ☐ Acct 1 ☐ Acct 1 & 2 ☐ Acct 2 ☐ None
Code (four-digit coded output)
CID
