Appendix D: Device types to personality codes correlation
P/N 3102351-EN • REV 005 • ISS 28DEC18 239
Model
Device type
Personality code
CT1
Supervisory Latching
(4) Active - NO latching (Class B)
CT1
Supervisory Non
-Latching (3) Active - NO nonlatching (Class B)
CT1
Unlatch outputs
(3) Active - NO nonlatching (Class B)
CT1
Waterflow
(2) Alarm - NO delayed latching (Class B)
CT1
Waterflow No Delay
(1) Alarm - NO latching (Class B)
CT2
Alarm
(1) Alarm - NO latching (Class B)
CT2
Heat
(1) Alarm - NO latching (Class B)
CT2
Monitor
(3) Active - NO nonlatching (Class B)
CT2
Pull Station
(1) Alarm - NO latching (Class B)
CT2
Remote AC Fail
(3) Active - NO nonlatching (Class B)
CT2
Remote Drill
(3) Active - NO nonlatching (Class B)
CT2
Remote Reset
(3) Active - NO nonlatching (Class B)
CT2
Remote Signal Silence
(3) Active - NO nonlatching (Class B)
CT2
Smoke
(1) Alarm - NO latching (Class B)
CT2
Supervisory Latching
(4) Active - NO latching (Class B)
CT2
Supervisory Non
-Latching (3) Active - NO nonlatching (Class B)
CT2
Unlatch
Outputs (3) Active - NO nonlatching (Class B)
CT2
Waterflow
(2) Alarm - NO delayed latching (Class B)
CT2
Waterflow No Delay
(1) Alarm - NO latching (Class B)
DTS
Duct Alarm
(1) Alarm - NO latching (Class B)
DTS
Duct
Supervisory Latching (4) Active - NO latching (Class B)
DTS
Duct Supervisory Non
-Latching (3) Active - NO nonlatching (Class B)
HC
D
Heat Fixed + CO Alarm
(66) Fixed CO Active3 Latching
HCD
Heat Fixed + CO Monitor Latching
(66) Fixed CO Active3 Latching
HCD
Heat Fixed + CO Monitor Non
-Latching (69) Fixed CO Active3 Nonlatching
HCD
Heat Fixed + CO Supv Latching
(66) Fixed CO Active3 Latching
HCD
Heat Fixed + CO Supv Non
-Latching (69) Fixed CO Active3 nonlatching
HCD
Heat ROR + CO Alarm
(65) ROR CO Active3 Latching
HCD
Heat ROR + CO Monitor Latching
(65) ROR CO Active3 Latching
HCD
Heat ROR + CO Monitor Non
-Latching (68) ROR CO Active3 nonlatching
HCD
Heat ROR + CO Supv Latching
(65) ROR CO Active3 Latching
HCD
Heat ROR + CO Supv Non
-Latching (68) ROR CO Active3 nonlatching
HFS
/HFD
Heat
(1) Alarm - NO latching (Class B)
HRS
/HRD
Heat ROR
(1) Alarm - NO latching (Class B)
IM
Monitor
(1) Alarm - NO latching (Class B)
