Chapter 2: Front panel programming
64 P/N 3102351-EN • REV 005 • ISS 28DEC18
Option Behavior when user key is pressed
Used for manual evacuation in the Canadian marketplace. Pressing
the Alarm ON button places the control panel in the alarm condition,
activates all drillable outputs which include all notification appliance
circuits and all sounder bases, and
signals the central station with CID
115. The panel still responds to initiating device circuits that are
activated while sounding a manual evacuation. The Alarm ON event
is restored upon panel reset. If Alarm ON is initiated while reset is in
progress, the event will be restored at the end of reset.
To meet CAN/ULC-S527requirements, User Key 1 default is Alarm
ON when the Canadian marketplace is selected.
To set up a programmable key:
1. Press the Menu button and choose Program.
2. Choose Programmable Keys.
3. Enter a level two password.
4. Choose the key to be programmed.
5. Choose Edit List or New List. Both commands let you select a function and edit the list of
correlation groups assigned to the key. The difference between the two is that:
• Edit List lets you makes changes to a key that has already been programmed. Choose
this command to change the key’s function, or edit the list of correlation groups
assigned to it.
Note: If you select Edit List for a key that has not yet been programmed, the message
“Nothing to Edit” is displayed. Choose New List instead.
• New List can be used to set up a new programmable key or to overwrite the current
programming of a key that has already been set up.
6. Choose a function to assign to the key.
None
Activate
Unlatch
Restore
Note: To disable a programmed key, choose None.
7. If you chose Unlatch in step 6:
• Press Enter to reopen the previous menu, and then choose Save.
— or —
Press the Menu button to exit menu mode without saving.
The button is now completely programmed to unlatch all latched outputs globally.
