15. Perform some temperature measurements
15.1. Perform a measurement of ambient temperature
➢ Connect a Pt100 temperature probe (available as option) on C1 connection on the top of the analyser.
➢ Turn on the instrument Home screen is displayed with measurement menu highlighted.
➢ Press OK.
The analyser performs the auto-zero: remaining time and a progress bar are displayed on the screen. However it is possible to reach the
temperature menu during the auto-zero.
➢ Go to “Ambient Temp.” with the keypad then press OK.
The temperature detected by the Pt100 probe is displayed on the analyser.
15.2. Perform a measurement of flue gas temperature
➢ Connect the flue gas probe on the analyser.
➢ Turn on the analyser. Home screen is displayed with measurement menu highlighted.
➢ Press OK.
The analyser performs the gas auto-zero: remaining time and a progress bar are displayed on the screen. However it is possible to reach
the temperature menu during the auto-zero.
➢ Go to “Flue gas Temp.” with the keypad then press OK.
The screen displays the flue gas temperature detected by the thermocouple probe of the flue gas probe.
15.3. Perform an ambient temperature measurement with the internal sensor
➢ Turn on the instrument Home screen is displayed with measurement menu highlighted.
➢ Press OK.
The analyser performs the auto-zero: remaining time and a progress bar are displayed on the screen. However it is possible to reach the
temperature menu during the auto-zero.
➢ Go to “Internal Temp.” with the keypad then press OK.
The screen displays the NTC temperature detected by the analyser.
15.4. Perform a Flow/Return temperature measurement
➢ Connect 2 Velcro type (SKV 150) or lamella contact type (SKCT) thermocouple probes on the Kigaz.
➢ Turn on the instrument. Home screen is displayed with measurement menu highlighted.
➢ Press OK.
The analyser performs the auto-zero: remaining time and a progress bar are displayed on the screen. However it is possible to reach the
temperature menu during the auto-zero.
➢ Go to “Flow/Return Temp.” with the keypad then press OK.
The screen displays the T1 temperature and the T2 temperature and the delta of temperature (ΔT) detected by the analyser.
15.5. Link the measurement to a customer
When the measurement has been performed, it is possible to link it to a customer registered in the analyser or to a customer unregistered in the
analyser that must be created.
➢ Press the function button.
The analyser displays the list of recorded customers.
➢ Select a customer with up and down arrows then press OK or create a customer (see page 22) then select it.
The analyser displays the list of available boilers.
➢ Select the boiler with up and down arrows then press OK or create a boiler (see page 23) then select it.
The analyser backs to the measurement screen.
15.6. Add the measurement to a group
The group function has to be activated (see page 17).
Once the measurement is linked to a customer and a boiler, it is possible to add it in a group in the instrument, or create a group:
The analyser proposes to add the measurement to a group.
➢ Go to YES and press OK.
➢ Go to the required group with the arrows and press OK, or create a group (see page 24).
The analyser backs to the measurement screen.
15.7. Print the results
It is possible to print the results on the ticket:
➢ Press the function button.
Results are printed on the ticket.
See page 17 for the printing configuration.
Perform some temperature measurements 31
