1.1.2. Presentation of the keypad and screen
1.1.3. Connection of the analyser
8 Introduction
T1 and T2 thermocouple
connections
C1 connection for external probe
(Pt100 temperature, CH
4
,...)
Flue gas probe connection
P- pressure tap
P+ pressure tap
USB
connection
Top view Bottom view Right side view
Function keys
On/Off button
OK button
Esc button
Home screen
Customers menu
Setting menu
Measurement menu
Procedures menu
Information menu
Light for battery
charging
Power supply
Gas outlet
Directional arrows
