Kinco KS Series User Manual

Kinco-KS series
11
KS105C2-16DT has 2 CAN ports, CAN1 and CAN2. CAN2 can support CANopen master
and free protocol.CAN1 can support CANopen slave and free protocol.
2.2.4 Expansion modules
KS105-16DT has expansion port, it can connect KS series expansion modules
CAN1 port of KS105C2-16DT can work as expansion port, also it support protocol.
Users can use them directly without setup, PLC can identify it automatically.( only one
between expansion or CANopen communication)
CPU can connect expansion modules with standard double wires directly. Expansion modules
have one input port and one output port. It is convenient to connect multiple expansion
modules.
Pls reference below figure.
We don’t need to setup address for connecting expansion modules. The real address in the net
depend on the turn that KincoBuilder configurate hardware.
