Kinco-KS series
27
9
A/B phase quadrature counter
Clock A
Clock B
HSC1
Mode
Description
I0.4
I0.6
I0.3
I0.2
0
Single-phase up/down counter
with internal direction control:
SM47.3
Clock
1
Reset
2
Reset
Start
3
Single-phase up/down counter
with external direction control
Clock
Direction
4
Reset
Direction
6
Two-phase counter
with up/down clock inputs
Clock
Down
Clock Up
7
Reset
9
A/B phase quadrature counter
Clock A
Clock B
10
Reset
HSC 2
Mode
Description
I0.4
I0.5
0
Single-phase up/down counter
with internal direction control:SM57.3
Clock
9
A/B phase quadrature counter
Clock A
Clock B
HSC 3
Mode
Description
I0.6
I0.7
0
Single-phase up/down counter
with internal direction control:SM127.3
Clock
9
A/B phase quadrature counter
Clock A
Clock B
4.2.2 Control Byte and Status Byte
Control Byte
In SM area,each high-speed counter is assigned control byte to save its configuration
data: one control word (8 bit), current value and pre-set (double-integer with 32 bit). Initial
value of current assigned value. If the current value is written in the high-speed counter, it
will start counting from that value. Please see below:
