Kinco KS Series User Manual

Kinco-KS series
32
execute HSC instruction again.
If SM141.0 is 1,it means “CV=PV” interrupt is cyclic execution.When the last PV interrupt
finishes execution,PLC will take the current counting value as reference to calculate new
value for PV interrupt,then it will start to compare the counting value and execute “CV=PV”
interrupt and so forth.This process will execute cyclically.
For example,it sets 3 PV values,such as 10,1000 and 1000.And the current counting value is
100 before HSC starts,then the value for every interrupt is as following table.
Current
counting value
Interrupt times
First value
Second value
Third value
100
1st time
110
1110
2110
2110
2nd time
2120
3120
4120
4120
3rd time
4130
5130
6130
…
N time
…
…
…
4.2.4 “CV=PV” Envent No.
When it uses single PV mode, the HSC will be fully compatible with K5 (Include “CP=PV”
event No.).
When it uses multiple PV mode, the HSC will assign a new event No. for 32 PV, as shown in
following table.
High speed
counter
Interrupt No.
Description
HSC0
64
“CV=PV”interrupt of 1st PV
65
“CV=PV”interrupt of 2nd PV
…
…（Plus 1）
95
“CV=PV”interrupt of 32nd PV
HSC1
96
“CV=PV”interrupt of 1st PV
97
“CV=PV”interrupt of 2nd PV
…
…（Plus 1）
127
“CV=PV”interrupt of 32nd PV
HSC2
128
“CV=PV”interrupt of 1st PV
129
“CV=PV”interrupt of 2nd PV
