2.2.5 High Speed Counter and High Speed Pulse Output
KS provides 4 high speed counters (HSC0~HSC3).High speed counter supports multiple
modes: single phase, CW/CCW(Up/Down),AB phase (1 multiplication and 4
multiplication).All can support up to 200KHz(Include single phase and AB phase).
KS provides 4 high speed pulse outputs(Q0.0,Q0.1 and Q0.4, Q0.5).All support PTO and
PWM.Q0.0 and Q0.1 ,Q0.4support up to 200KHz (The resistor of load should be less than
1.5KΩ),Q0.5 supports up to 10KHz.
2.2.6 Edge Interrupts
I0.0-I0.3 in CPU support edge interrupt function, it can execute interrupt by rising edge and
falling edge of input signal. By using this function, it can capture the rising edge and falling
edge of input signal quickly. For some input signal whose pulse width is less than the CPU
scan time, it can respond quickly.
2.2.7 Data Retentive and Data Backup
Data retentive means the data in RAM can retain after power failure.CPU provides a lithium
battery (Replaceable but un-rechargeable) for data retentive.When CPU loses power, the data in
the RAM will be maintained by the lithium battery, and the retentive ranges will be left
unchanged at next power on. Through [Hardware] configuration in KincoBuilder, user can
select the type of data retentive (Such as V,C area) and the range. The life of battery is 5 years
and the retaining duration is 3 years at normal temperature.
Data backup is that CPU provides an E
2
PROM to store data permanently. At power on, the
CPU will restore the data from E
2
PROM into RAM to execute.
Note: Because E
2
PROM has a writing limit of 1 million times, users should avoid to write data
into data backup area frequently.
There are 448 bytes in V area for data backup (VB3648--VB4095),the data in this area will
