Kinco KS Series User Manual

Kinco-KS series
33
…
…（Plus 1）
159
“CV=PV”interrupt of 32nd PV
HSC3
160
“CV=PV”interrupt of 1st PV
161
“CV=PV”interrupt of 2nd PV
…
…（Plus 1）
191
“CV=PV”interrupt of 32nd PV
4.2.5 How to use high speed counter
 Method 1:Use instructions for programming
1)Configure the control byte of HSC and define the current value (i.e. starting value) and the
preset value.
2)Use HDEF instruction to define the counter and its operation mode.
3)(Optional) Use ATCH instruction to define the interrupt routines.
4)Use HSC instruction to start the high-speed counter.
 Method 2:Use wizard of HSC
In KS PLC, it provides configuration wizard for high speed counter. Users can use the wizard
to configure all high speed counters and don’t need to program. The wizard is as following
figure:
After using wizard to configure HSC, user also can use “Method 1” to modify the parameters
of HSC.
