Kinco KS Series User Manual

Kinco-KS series
28
HSC0
HSC1
HSC2
HSC3
Description
SM37.0
SM47.0
SM57.0
SM127.0
Effective electrical level of reset signal ：
0=high；1=low
SM37.1
SM47.1
SM57.1
SM127.1
Effective electrical level to start signal：0=high；
1=low
SM37.2
SM47.2
SM57.2
SM127.2
Orthogonal counter rate：0=1x rate；1=4x rate
*
SM37.3
SM47.3
SM57.3
SM127.3
Counting direction:0=Decrease；1=Increase
SM37.4
SM47.4
SM57.4
SM127.4
Write counting direction in HSC? 0= NO; 1=
Yes
SM37.5
SM47.5
SM57.5
SM127.5
Write new pre-set value in HSC? 0= NO; 1=
Yes
SM37.6
SM47.6
SM57.6
SM127.6
Write new current value in HSC? 0= NO; 1=
Yes
SM37.7
SM47.7
SM57.7
SM127.7
Allow this high-speed counter? 0=NO; 1= YES
HSC0
HSC1
HSC2
HSC3
Description
SMD38
SMD48
SMD58
SMD128
Current value
SMD42
SMD52
SMD62
SMD132
Pre-set value
HSC0
HSC1
HSC2
HSC3
Description
SM141.0
SM151.0
SM161.0
SM171.0
Use multiple preset value:0=No. 1=Yes.
SM141.1
SM151.1
SM161.1
SM171.1
Preset value type:0=Absolute value.
1=Relative value.
SM141.2
SM151.2
SM161.2
SM171.2
Preset value comparison interrupt
(“CV=PV”) cyclic execution.
0=No. 1=Yes.
Note:Only valid when preset value is
relative value.
SM141.3
SM151.3
SM161.3
SM171.3
Reserved
SM141.4
SM151.4
SM161.4
SM171.4
Update multiple PV segment and preset
value:0=No. 1=Yes
SM141.5
SM151.5
SM161.5
SM171.5
Reset interrupt variable:0=Yes. 1=No.
SM141.6
SM151.6
SM161.6
SM171.6
Reserved
SM141.7
SM151.7
SM161.7
SM171.7
Reserved
HSC0
HSC1
HSC2
HSC2
Description
