37
CircuitBlockDiagram
StandardConnectorWireSequence
Connecttothecontroller DisplayOutlet ConnectionInterface
Table：Standardconnectorwiresequencetable
Standard
Wiring
Standard Wiring
Color
Function
1
Red（VCC）
DisplaypowerWire
2 Blue(K) Controller Power Control
Wire
3 Black(GND) DisplayGroundWire
4 Green(RX) Display Data Receiving
Wire
5 Yellow(TX) Display Data
TransmissionWire
Note:Someproductshavewaterproofconnectorsfortheleads,andtheuser
cannotseethecoloroftheleadsintheharness.

